Industry certification:

USB-IF certification: Through strict USB-IF association certification, it fully complies with USB2.0 and USB3.1 Gen1 standards, ensuring compatibility with various USB devices and stability of data transmission.

Environmental certification: The product complies with the EU RoHS 2011/65/EU directive, is free of harmful substances such as lead, mercury, and cadmium, and meets ELV 2000/53/EC environmental requirements, ensuring green and environmentally friendly products from the source.

Safety certification: Obtained UL 94 V-0 flame retardant rating certification, the material has excellent flame retardant performance; Through CE and FCC electromagnetic compatibility certification, the product will not cause electromagnetic interference to surrounding electronic devices during normal use, and can also resist external electromagnetic interference, ensuring safe and stable operation of the equipment.

Industry standards:

For industrial applications, meeting the ISO 13849-1 mechanical safety standard ensures the reliability and safety of connectors in complex industrial machinery operating environments.

In terms of automotive electronic applications, it meets the AEC-Q200 passive component testing standard and has undergone multiple rigorous tests such as vibration, impact, and temperature cycling, making it suitable for the high standard requirements of the automotive industry.

Production control:

Advanced ERP systems are used in the production process to conduct full traceability management of raw material procurement, production processing, and finished product inspection, ensuring the traceability of product quality.

Each batch of products undergoes 100% electrical performance testing, including contact impedance testing, insulation resistance testing, withstand voltage testing, and 48 hour salt spray testing to ensure product quality meets high standards.

For more information, please contact us:

- Hotline: +86 13310802726

- Email: mc13310802726@163.com

Installation requirements:

Strict temperature control is required during welding. It is recommended to keep the peak value of the reflow soldering temperature curve within 255 ° C and the duration not exceeding 60 seconds to avoid damaging the terminals and LCP insulation due to high temperature.

When installing four foot full mount SMT, a high-precision surface mount machine is required to ensure precise alignment between the pins and PCB pads, with a deviation controlled within ± 0.05mm, to ensure good electrical connection and mechanical stability.

Usage restrictions:

Although the product can withstand a high current of 15A, in practical applications, it is necessary to reduce the rating reasonably based on factors such as PCB copper foil thickness and heat dissipation conditions. If the PCB copper foil thickness is less than 35 μ m, it is recommended that the current not exceed 10A to avoid overheating of the circuit.

This product with non waterproof design is strictly prohibited from use in humid environments to prevent short circuits and corrosion risks.

Compatibility Description:

When connected to a USB 2.0 device, the data transfer rate automatically switches to 480Mbps; When connected to USB 3.1 devices, high-speed transmission of 5Gbps can be achieved.

When using non certified USB cables, there may be issues such as PD protocol handshake failure and unstable data transmission. It is recommended to pair them with USB-IF certified cables to ensure optimal performance.

Maintenance suggestion:

Regularly use compressed air or anti-static brushes to clean the dust inside the interface, to prevent metal foreign objects from entering the interface and causing short circuits.

When not in use for a long time, it is recommended to use a dust cover to protect the interface, prevent oxidation and deformation of the interface, and extend the product's service life.
