This product strictly follows the Type-C interface full standard established by the USB Implementers Forum (USB-IF), including pin definition, electrical performance, data protocol compatibility, etc., to ensure perfect compatibility with all Type-C plugs and devices that comply with USB-IF certification, avoiding functional failure or device damage caused by protocol incompatibility.

In terms of environmental protection and safety compliance, all materials have passed ROHS 2.0 environmental certification and do not contain harmful substances such as lead, mercury, cadmium, etc. They comply with environmental regulations in major markets such as the European Union, the United States, and China, and can be used in areas with strict environmental requirements such as consumer electronics and medical equipment. In terms of electrical safety, the product has passed safety standards such as GB 4943.1-2011 and IEC 60950-1, and has overcurrent protection and overvoltage protection characteristics. When the current exceeds the rated value of 15A or the voltage is abnormal, it can quickly cut off some circuits to prevent equipment from burning out or electric shock risks; The insulation resistance test reaches 100M Ω or above, and the leakage current is ≤ 0.1mA, ensuring the safety of users and equipment.

In terms of material and reliability compliance, 304 stainless steel structural components comply with ASTM A240 standard, high conductivity copper conductors comply with GB/T 5231-2022 copper and copper alloy processing material standard, LCP black adhesive complies with UL 94 V-0 flame retardant level, and all materials have been verified by third-party testing agencies to ensure that material performance meets standards. In addition, the product also undergoes high and low temperature cycle testing (-40 ℃ to 85 ℃, 500 cycles) and wet heat testing (40 ℃, 95% RH, 1000 hours) to maintain stable performance in extreme environments, meeting the reliability requirements of various fields such as consumer electronics, industry, and automotive.

For more information, please contact us:

- Hotline: +86 13310802726

- Email: mc13310802726@163.com

The installation process must strictly follow the SMT process requirements for the four pin plug-in board on the board: the reflow soldering temperature should be controlled at 240 ℃ -260 ℃ (the upper limit of LCP black glue's high temperature resistance is 260 ℃, exceeding 270 ℃ may cause deformation of the shell), and the welding time is recommended to be 30-60 seconds to avoid long-term high temperature staying and damaging the internal conductor or insulation structure of the mother socket; After welding, it is necessary to inspect the four pin solder joints with a magnifying glass to ensure that there is no virtual soldering or continuous soldering. If any abnormal solder joints are found, they should be repaired in a timely manner to prevent poor contact during later use.

When using it in daily life, the insertion and removal should be done vertically and steadily with force, avoiding tilting or rotating insertion and removal - the 16 PIN pins are densely arranged, and forcibly tilting may cause the pins to bend or break, leading to short circuits or data transmission interruptions; If excessive resistance is found when inserting the plug, it is necessary to check whether there are foreign objects (such as dust and metal debris) in the female socket interface. It can be cleaned with a dry soft brush before inserting, and do not directly insert forcefully.

In terms of maintenance and storage, it is necessary to avoid long-term exposure of the mother seat to humid (humidity>95% RH) and corrosive gases (such as industrial waste gas and acidic gases). Although 304 stainless steel is corrosion-resistant, long-term exposure to strong corrosive environments may still cause rust, affecting structural stability; The idle mother seat should be stored in a dry, room temperature (10 ℃ -30 ℃) environment, avoiding stacking with sharp objects to prevent scratches or damage to the LCP black rubber shell.

Special scenario usage precautions: If used in 15A high current scenarios (such as laptop fast charging), ensure that the connected devices and cables support 15A current carrying capacity to avoid heating due to insufficient cable current limit; If abnormal heating is found in the mother seat during equipment operation (temperature exceeding 60 ℃), the connection should be immediately disconnected to check for poor contact or load overload. After troubleshooting, the mother seat or equipment should be prevented from being damaged by high temperature before use.
