Interface standard certification: Complies with the Type-C interface specification developed by the USB-IF organization, passes USB 3.1 Gen2 protocol compatibility testing, and ensures interoperability with various Type-C devices.
Electrical safety certification: Passed UL 60950-1 electrical safety test, insulation resistance ≥ 1000M Ω, withstand voltage 1000V AC/1min without breakdown, avoiding leakage risk.
Environmental compliance requirements: Meet the EU RoHS 2.0 directive (2011/65/EU), with harmful substances such as lead and mercury content below 0.1%; Meets the limit requirements for 197 substances of high concern (SVHC) under REACH regulation and can be exported to European and American markets.
Production system certification: The production process complies with the IATF 16949 automotive electronics quality standard, and each batch of products has passed three factory tests: air tightness, insertion and extraction force, and temperature resistance, with a complete quality inspection report provided.


For more information, please contact us:

- Hotline: +86 13310802726

- Email: mc13310802726@163.com

1. Installation specifications
When SMT mounting, the welding temperature should be controlled at 260 ℃± 5 ℃, and the welding time should be ≤ 3 seconds to avoid deformation of the plastic base caused by high temperature. Before welding, it is necessary to clean the PCB board pads, remove the oxide layer and oil stains, ensure that the pins are completely attached to the pads, and prevent unstable current caused by virtual soldering. Avoid plugging and unplugging within 24 hours after installation, and wait for the solder to fully solidify to improve connection reliability.
2. Usage restrictions
It is strictly prohibited to use beyond the rated current of 5A. Long term overload can cause contact heating and oxidation, shortening the service life. Avoid using in humid environments (relative humidity>85%) or corrosive gas environments. It is recommended to use waterproof enclosures for outdoor equipment. When inserting or unplugging, force should be applied horizontally, and it is forbidden to tilt or pull the male head to prevent pin breakage or contact displacement of the plug-in board.
3. Storage conditions
The product should be stored in a dry and ventilated warehouse, with an ambient temperature controlled between -10 ℃ and 40 ℃, a relative humidity of ≤ 60%, and kept away from direct sunlight and organic solvents. Unused products should be kept sealed in their original packaging, and welding should be completed within 48 hours after opening to avoid pin oxidation affecting conductivity.
4. Maintenance tips
Regularly clean the surface stains of the contacts with a dry cotton swab, and prohibit the use of corrosive cleaning agents such as alcohol. If there is poor contact, it is necessary to check whether the contacts are oxidized or the pins are loose. Non professionals are prohibited from disassembling on their own. It is recommended to contact the manufacturer to replace the components.
