Product description:

This product is a high-performance Type-C USB socket, with 16-pin interface, SMT design of four-pin board, 5A current support and three-mode

function, which is suitable for connecting various electronic devices. The product has column design, which ensures stable connection, is suitable

for high-intensity and high-frequency signal transmission, and is widely used in consumer electronics, industrial equipment and other fields.

Main features:

1. Support 5A current:

With 5A high current carrying capacity, it is suitable for equipment requiring high current transmission to ensure efficient power transmission.

2. Interface design:

16Pin interface, in line with USB Type-C standard, supports high-speed data transmission and charging functions, and meets the needs of various devices.

3. Three-die design:

Support three-mode function, compatible with more equipment types, suitable for different working environments.

4. On-board four-legged board SMT:

SMT design provides high-precision installation and excellent connection performance, and the four-legged structure on the board enhances the

installation stability.

5. Column design:

Provide column structure to enhance the tensile strength and stability of the interface and ensure the reliability in long-term use.

Statement of compliance:

This product strictly abides by international and industry certification standards to ensure its compliance in safety and environmental protection:

1. ISO 9001 quality management system certification:

Ensure that products meet international quality management standards in the design and production process.

2. REACH certification:

Comply with EU regulations on registration, evaluation, authorization and restriction of chemicals, and ensure that the materials are harmless and

environmentally friendly.

3. RoHS certification:

Comply with the EU directive on the restriction of harmful substances in electronic and electrical equipment, ensure that the products do not contain

harmful substances and protect the health of users.

Contact information:

-Hotline: 13310802726

-E-mail: mc13310802726@163.com

-Company Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further understanding, please feel free to contact us and we will provide you with professional support.

Points for attention in using the three-mode USB interface with four-pin plug-in board SMT L=7.35 5A on Type-C mother board 16Pin:

1. Installation and welding:

-Please ensure that the welding surface is clean during installation, so as to avoid oil pollution or dust affecting the welding quality.

-The welding temperature should be controlled within the specified range. Excessive temperature may affect the stability of the internal structure of

the interface.

-Ensure that the four-pin plug board is welded firmly, so as to ensure the stability of connection and the reliability of long-term use.

2. Electrical performance:

-This product is designed for the maximum current of 5A, so it can be used within this range to ensure normal operation and prolong product life.

-Avoid current overload or abnormal voltage to prevent damage to interfaces and related circuits.

3. Plug-in operation:

-Please ensure that the operation is gentle when plugging and unplugging, so as to avoid excessive contact between the plug and the socket, so as to

avoid damaging the contact points.

-When plugging and unplugging, it should follow the forward plugging and unplugging, so as to avoid the asymmetric insertion of the plug into the

interface, which may cause the interface damage or poor contact.

-Plugging times should be controlled within the design requirements to avoid excessive wear.

4. Three models:

-This interface supports USB 3.1, USB 2.0 and power transmission (PD) functions. Please ensure that the equipment meets the technical requirements of

the three-mode interface.

-During use, please pay attention to the compatibility of equipment to ensure stable connection and efficient data transmission of all modes.

5. Cleaning and maintenance:

-If the interface surface is contaminated with moisture or dust, please wipe it with a clean and soft cloth in time to avoid using chemical cleaners.

-Check the pins and connecting column components of the interface regularly to ensure that they are not damaged or aged, and maintain good contact

 and stability of the interface.

6. Application environment:

-This product is suitable for general electronic equipment and industrial control fields, but long-term exposure to high temperature, high humidity or

 corrosive environment is not recommended.

-Avoid strong mechanical impact or scratches on the interface, so as not to affect the plug-in performance.

7. Storage conditions:

-Unused products should be stored in a dry, cool and ventilated environment to avoid direct sunlight.

-Please avoid storing the product in an environment with too high or too low temperature, so as not to affect the product performance.
