Product Description:

This product is a high-performance Type-C USB female connector with a 6Pin interface, supporting both 4-pin board mount and 4-pin full-surface SMT

mounting options. It complies with USB interface standards and supports data transmission with high stability and reliability. Suitable for use on automated

production lines, it is widely applied in consumer electronics, industrial equipment, and communication products.

Key Features:

1. USB Interface Standard:

   This product complies with USB standards and supports high-speed data transmission, meeting the connection needs of various devices.

2. 6Pin Interface Design:

   The 6Pin interface design ensures stable and efficient data transmission, suitable for various USB devices.

3. 4-Pin Board Mount/4-Pin Full-Surface Structure:

   Offers two installation options, suitable for different application needs, simplifying the production and installation process and improving efficiency.

4. SMT Mounting Technology:

   The SMT (Surface-Mount Technology) ensures high precision and stability of the product, making it ideal for large-scale automated production.

5. High Compatibility:

   Suitable for a wide range of devices and industries, particularly in the fields of consumer electronics, industrial equipment, and communication products.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with the EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring the materials are safe and environmentally

friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user

health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

Type-C Female Connector 6Pin Board-Mount Four-Pin/Full-Pin SMT L=7.4 USB Interface Usage Notes:

1. Installation and Soldering:

   - Ensure the soldering area is clean and free of oil or dust to maintain soldering quality.

   - The soldering temperature should be controlled within the recommended range to prevent damage to the connector or PCB.

   - Ensure the connector is properly aligned with the PCB and securely soldered to prevent poor contact.

2. Electrical Performance:

   - This product supports USB 3.1 standards, offering high-speed data transmission with a maximum rate of 10Gbps.

   - The four-pin or full-pin design ensures reliable electrical connections, suitable for high-frequency data transmission applications.

   - This product is widely used in USB-enabled electronic devices such as computers, mobile devices, and consumer electronics.

3. Insertion and Extraction:

   - Handle insertion and extraction gently to avoid damaging the connector or plug.

   - Ensure proper alignment between the plug and the socket to prevent misalignment and poor contact.

4. Material Properties:

   - The housing is made of high-quality materials, offering corrosion resistance and wear resistance to ensure long-term stability.

   - The internal pins are made from high-conductivity materials to ensure excellent electrical transmission performance.

5. Operating Environment:

   - This product is widely used in applications requiring high-speed data transmission, such as consumer electronics, communication devices, and

industrial equipment.

   - Avoid use in high-temperature, humid, or highly corrosive environments to maintain stable performance.

6. Storage Conditions:

   - Store unused products in a dry, ventilated environment, away from direct sunlight.

   - The storage environment should avoid extreme temperatures to prevent degradation of electrical performance or material aging.

For more product information or technical support, please contact us:

- Hotline: 13310802726

- Email: mc13310802726@163.com
