Certification and standards:

It conforms to the basic specification of USB-IF Type-C 1.3, and has passed the basic tests such as plug-in force and electrical performance.

Meet the environmental protection requirements of RoHS 2.0 and REACH, and the shell and terminal are made of halogen-free materials.

Patent statement:

By adopting the design authorized by the invention patent (patent number: ZL201610389114.9), the end customers need not worry about patent

disputes.

EU restrictions:

The European Union standard EN IEC 62680-1-3 explicitly prohibits the use of 6PIN Type-C as the charging interface, and only 12/16/24PIN scheme

is allowed.

Supply chain management:

Suppliers need to pass ISO 9001 certification to ensure that raw materials meet environmental protection and safety standards.

Use restrictions:

It only supports the charging function and cannot be used for data transmission or video output devices. It needs to be clearly marked in the package

and instructions.

Welding process:

It is suggested that the peak temperature of SMT reflow soldering should be ≤260℃ to avoid plastic deformation caused by high temperature.

Protection design:

If waterproof function (such as IPX4) is required, additional silicone sealing ring (non-standard) shall be installed, and the gap between the housing and

PCB shall be ≤ 0.1 mm.. .

Storage and maintenance:

Avoid exposure to high temperature (> 85℃) or high humidity environment to prevent terminal oxidation.

Clean the dust in the interface regularly to avoid poor contact caused by foreign objects.

Obedience:

In the EU market, it needs to be replaced by the 12/16/24PIN scheme, so as to avoid the products being removed from the shelves due to non-compliance

with laws and regulations.

After-sales service:

Provide one-year warranty, support return service, and keep the original packaging and purchase certificate. Use restrictions:

It only supports the charging function and cannot be used for data transmission or video output devices. It needs to be clearly marked in the package

and instructions.

Welding process:

It is suggested that the peak temperature of SMT reflow soldering should be ≤260℃ to avoid plastic deformation caused by high temperature.

Protection design:

If waterproof function (such as IPX4) is required, additional silicone sealing ring (non-standard) shall be installed, and the gap between the housing and

PCB shall be ≤ 0.1 mm.. .

Storage and maintenance:

Avoid exposure to high temperature (> 85℃) or high humidity environment to prevent terminal oxidation.

Clean the dust in the interface regularly to avoid poor contact caused by foreign objects.

Obedience:

In the EU market, it needs to be replaced by the 12/16/24PIN scheme, so as to avoid the products being removed from the shelves due to non-compliance

with laws and regulations.

After-sales service:

Provide one-year warranty, support return service, and keep the original packaging and purchase certificate.
