Product Description:

This product is a high-performance Type-C USB female connector with a 6Pin interface design and SMD mounting style. It complies with USB 2.0 standards

and supports high-speed data transmission, making it suitable for connecting various electronic devices. The new model features a more compact size and

optimized connection performance, widely used in consumer electronics, industrial equipment, automotive electronics, and more.

Key Features:

1. USB 2.0 Interface Standard:

   This product complies with USB 2.0 standards and supports 480Mbps high-speed data transmission, meeting the connection needs of most devices.

2. 6Pin Interface Design:

   The 6Pin interface design ensures stable data transmission and is compatible with various USB 2.0 devices.

3. SMD Mounting Style:

   The SMD design saves space, making it suitable for various device connection needs, while providing a more stable connection.

4. Compact Size:

   The product features a compact design, ideal for applications with limited space and high-density installation requirements.

5. High Compatibility:

   Suitable for a wide range of devices, particularly in consumer electronics, industrial equipment, automotive electronics, and more.

Compliance Statement:

This product strictly adheres to international and industry certification standards, ensuring its compliance with safety and environmental regulations:

1. ISO 9001 Quality Management System Certification:

   Ensures the product meets international quality management standards during design and production.

2. REACH Certification:

   Complies with the EU chemicals registration, evaluation, authorization, and restriction regulations, ensuring the materials are safe and environmentally

friendly.

3. RoHS Certification:

   Complies with the EU Restriction of Hazardous Substances (RoHS) directive, ensuring the product is free from harmful substances and promotes user

health.

Contact Information:

- Hotline: 13310802726

- Email: mc13310802726@163.com

- Address: Dalingshan Town, Dongguan City, Guangdong Province

If you have any questions or need further information, feel free to contact us, and we will provide professional support.

Type-C Female Connector 6Pin Vertical Mount L=6.0/6.5/6.8 USB 2.0 New Version Usage Notes:

1. Installation and Soldering:

   - Ensure the soldering area is clean, free from oil or dust to maintain soldering quality.

   - Control the soldering temperature within the recommended range to prevent damage to the connector or PCB.

   - Ensure proper alignment between the connector and PCB during installation, and securely solder the pins to prevent poor contact.

2. Electrical Performance:

   - This product supports USB 2.0 standards, ensuring high-speed and stable data transmission.

   - The vertical mount design offers a more compact layout, suitable for space-constrained applications.

   - This connector is suitable for various electronic devices, including computers, mobile devices, and consumer electronics.

3. Insertion and Extraction:

   - Handle insertion and extraction gently to avoid excessive force. Ensure the plug is properly aligned with the socket to prevent damage.

   - When inserting the plug, ensure it is aligned correctly with the socket for stable electrical connection.

4. Material Properties:

   - The housing is made of high-strength materials, offering excellent corrosion and oxidation resistance for long-term stable use.

   - The pins are made from high-conductivity materials to ensure electrical stability during high-speed data transmission.

5. Operating Environment:

   - This product is widely used in computers, communication devices, consumer electronics, and other applications.

   - Avoid use in humid, highly corrosive, or high-temperature environments to ensure stable performance.

6. Storage Conditions:

   - Store unused products in a dry, ventilated environment, away from direct sunlight.

   - Avoid storing in extreme temperatures to prevent material aging or performance degradation.

For more product information or technical support, please contact us:

- Hotline: 13310802726

- Email: mc13310802726@163.com
